Tablet Press: The Core Engine of Intelligent Solid Preparation Manufacturing

In terms of application fields, tablet presses are most widely used in the pharmaceutical industry. Whether for common tablets, vitamin tablets, or complex dosage forms such as controlled-release preparations and targeted tablets, they rely on tablet presses to complete the forming process.

Image Source：699pic.com

In pharmaceutical production, tablet presses need to meet GMP standards. Their fuselage is mostly made of stainless steel with fine polishing treatment to prevent material adhesion and cross-contamination, and they have a structural design for quick disassembly and cleaning to adapt to the production switching of multiple varieties and small batches. For example, when pressing multi-layer tablets, the tablet press needs to achieve precise stacking of different drug layers through the collaborative operation of multiple sets of molds and feeding devices, which not only ensures the stage-by-stage release of drug efficacy but also avoids mutual interference between components. In the production of new preparations such as vaccine adjuvant tablets, the tablet press also needs to have a low-temperature pressing function to prevent heat-sensitive components from inactivating, which puts forward higher requirements for the equipment's temperature control system and pressure conduction mechanism.

In terms of technicalprinciples, the core of the tablet press lies in the collaborative operation of the pressure system and the mold system. The mainstream tablet presses are divided into single-punch tablet presses and rotary tablet presses. The single-punch tablet press has a simple structure and is suitable for small-batch production in laboratories. It completes the pressing through a single-step cycle of upper punch descent, material filling, pressure forming, and lower punch pushing. The rotary tablet press adopts a multi-punch circular motion design for continuous production. Its workflow includes uniform filling of material particles into the die holes by the feeder, synchronous pressurization of the upper and lower punches under the action of the cam track to make the material dense in the die holes, and then the lower punch pushes out the tablets.

The key performance indicators of the tablet press include the pressure adjustment range, tablet pressing speed, weight difference accuracy, and hardness uniformity. The pressure adjustment range determines the nature of the materials that the equipment can process. For example, when pressing traditional Chinese medicine tablets, due to the high fiber content of the materials, greater pressure is required to ensure forming, while vitamin tablets can be pressed with lower pressure. The pressure adjustment of modern tablet presses is mostly realized through the combination of a frequency conversion motor and a hydraulic system, and the pressure parameters can be switched within a few seconds. The weight difference accuracy depends on the design of the feeder. At present, advanced tablet presses use double-screw feeding or vibration feeding methods, combined with online weighing sensors, to control the weight difference within±2%. In terms of hardness uniformity, the rotary tablet press can adjust the pressure value of each punch in real time through multi-punch synchronous pressing and pressure feedback system to avoid hardness deviation caused by mold wear or uneven material distribution.

Under the trend of intelligence and digitization, tablet presses are evolving towards "Industry 4.0" standards. Some equipment is integrated with IoT modules, which can upload real-time data such as pressure, temperature, and production quantity during the pressing process to the factory management system, facilitating quality traceability and production scheduling. For example, in pharmaceutical tablet pressing, the equipment can automatically generate the process parameter curve of the pressing process. When an index deviates from the preset range, the system will automatically alarm and adjust the parameters to reduce manual intervention. In addition, a machine learning-based fault early warning system has gradually been applied to tablet presses. By analyzing historical operation data, it can predict potential faults such as punch wear and bearing overheating in advance, reducing downtime maintenance costs.

With the popularization of the concept of green production, the energy-saving design of tablet presses has also become the focus of technological innovation. New tablet presses mostly use servo motors instead of traditional asynchronous motors, reducing energy consumption by more than 30%; the optimization of the equipment's sealing structure reduces dust emission, and with an efficient dust removal system, it can meet environmental protection emission requirements; in terms of the cooling system, some tablet presses use circulating water cooling instead of air cooling, which reduces noise and improves heat dissipation efficiency. These technological improvements not only meet the needs of sustainable development but also reduce the long-term operation cost for enterprises.

From laboratory research and development to large-scale production, the tablet press continues to promote the technological innovation of the solid preparation field with its flexible adaptability and stable performance. Whether it is to meet the requirements of the generic drug consistency evaluation in the pharmaceutical industry or to meet the personalized customization needs of the food industry, the technological progress of the tablet press has always been in sync with industrial demands. Its future development will be more closely combined with intelligent control, green manufacturing, and precision forming technology to provide reliable equipment support for the production of solid preparations in more fields.
